Ezzi Vision is the leading provider of Zirbus freeze dryers, and other comprehensive range of laboratory equipment that Zirbus manufactures for wide-scale industries. The laboratory freeze dryers are characterized by a variety of customized options, ease of use, simplicity, and sleek design.

Zirbus Technology, with experience over 30 years of experience in the manufacturing and development of high-quality and robust freezer dryers, supplies a range of freezer dryers with different volumes ranging from 20 to 5,000 liters.

Ezzi Vision is the largest supplier of Zirbus freezer dryers, so laboratories, R&D, and manufacturing facilities can get all the equipment from VaCo Series Laboratory Freeze Dryer.

About VaCo Series Laboratory Freeze Dryer
This is entry-level series freeze dryer and lyophilizer with modular system that makes the dryer perfect for all your laboratory tasks. The housing is made of robust stainless steel and the units are optionally available with a -50C or -80C. These are built according to the new new EU F-Gases Regulation (EU) No. 517/2014 and only environment-friendly and natural refrigerant are used. Depending upon the application, different modules can be used with the basic unit.

Here is the list of options that are available offered by Zirbus freeze dryer manufacturers:

Acrylic glass chambers are available in different dimensions and the base plate represents the connecting piece to ice condensor. (Chamber lid with vacuum connection (NS 29/32) is available on request)
Stainless steel chamber is suitable in case the organic solvents or substances attack acrylic glass
Aluminium insert rack is available in 2 packages: heated and unheated packages
Stainless steel drying trays are available to match the shelves
Drying racks, made of stainless steel and incl. 3-way valve (NS 29/32), is ideal if the drying is taking place in exclusive glass flasks or ampoules
Ampoule adapter, for 16 ampoule, is also available to extend vacuum valve
Sealing device is an option available from VaCo 5 and it is requirement when producing lyophilizates in vials to seal them in vacuum after drying
Vacuum control is available to set different vacuum values
Zirbus vacuum pump which is an oil-sealed rotary vane pump or chemistry hybrid vacuum pump
Overview of VaCo Series
There are three different models available in VaCo series: VaCo 2, VaCo 5, VaCo 10. Here are the specification of each model:

VaCo 2

Capacitor volumes: 5 and 7 Liters
Condensor temperature: < -50°C or < -80°C
Condensor capacity: 2kg / 24h
Max. ice capacity: 3kg
Dimensions basic unit (WxHxD) (in mm): 490 x 440 x 470
Weight base unit: 45kg at -50°C and 55kg at -80°C
VaCo 5

Capacitor volumes: 16 Liters
Condensor capacity: 5kg / 24h
Max. ice capacity: 8kg
Dimensions basic unit (WxHxD) (in mm): 800 x 400 x 530
Weight base unit: 60kg at -50°C and 70kg at -80°C
VaCo 10

Capacitor volumes: 50 Liters
Condensor capacity: 15kg / 24h
Max. ice capacity: 20kg
Dimensions basic unit (WxHxD) (in mm): 750 x 900 x 750
Weight base unit: 75kg at -50°C and 85kg at -80°C
Laboratory Freeze Dryer VaCo 2
There are two models available for this series: VaCo 2 for -50°C and VaCo 2 for -80°C. Let’s look at the specifications for both of them:

VaCo 2 for -50°C

Condenser dimensions: -Ø 200 x 180mm
Volume: 5 or 7liters
Condenser temperature: -50°C
Ice capacity: 2kg/24h
Max. ice capacity: 3kg
Cooling System: One-stage, refrigerant according to latest F-Gas regulations
Outer dimensions (wxhxd): 490 x 450 x 470 mm
Basic unit weight: 45kg
Electrical connection: 230 V, 50/60 Hz
VaCo 2 for -80°C

Condenser dimensions: Ø 200 x 180mm
Volume: 5 or 7 liters
Condenser temperature: -80°C
Ice capacity: 2kg/24 hr
Max. ice capacity: 3kg
Cooling System: Two-stage, refrigerant used is as per latest F-Gas regulations
Outer dimensions (wxhxd): 490 x 450 x 470 mm
Basic unit weight: 58kg
Electrical connection: 230 V, 50/60 Hz
Overview of Laboratory Freeze Dryer VaCo 5
This series again comprises of two different models: VaCo 5 for -50°C and VaCo 5 for -80°C. Let’s look at the features of the following Zirbus freeze dryer:

VaCo 5 for -50°C

Condenser dimensions: Ø 270 x 280mm
Volume: 16 liters
Condenser temperature: -50°C
Ice capacity: 5kg/24 hr
Max. ice capacity: 8kg
Cooling System: One-stage, refrigerant used is as per latest F-Gas regulations
Outer dimensions (wxhxd): 800 x 450 x 580 mm
Basic unit weight: 60kg
Electrical connection: 230 V, 50/60 Hz
VaCo 5 for -80°C

Condenser dimensions: Ø 270 x 280mm
Volume: 16 liters
Condenser temperature: -80°C
Ice capacity: 5kg/24 hr
Max. ice capacity: 8kg
Cooling System: Two-stage, refrigerant used is as per latest F-Gas regulations
Outer dimensions (wxhxd): 800 x 450 x 580 mm
Basic unit weight: 75kg
Electrical connection: 230 V, 50/60 Hz
Like the previous two series, this series offers two models for two different temperatures: VaCo 10 for -50°C and VaCo 10 for -80°C. Let’s look at the specifications;

VaCo 10 for -50°C

Condenser dimensions: Ø 400 x 400 mm
Volume: 50 liters
Condenser temperature: -50°C
Ice capacity: 10kg/24 hr
Max. ice capacity: 12kg
Cooling System: One-stage, refrigerant used is as per latest F-Gas regulations
Outer dimensions (wxhxd): 700 x 900 x 700
Basic unit weight: 90kg
Electrical connection: 230 V, 50/60 Hz
VaCo 10 for -80°C

Condenser dimensions: Ø 400 x 400mm
Volume: 50 liters
Condenser temperature: -80°C
Ice capacity: 15kg/24 hr
Max. ice capacity: 20kg
Cooling System: Two-stage, refrigerant used is as per latest F-Gas regulations
Outer dimensions (wxhxd): 700 x 900 x 700 mm
Basic unit weight: 90kg
Electrical connection: 400 V, 50/60 Hz
Choose Ezzi Vision, Choose quality and Seamless Operations.
Do you need a high-performing freezer dryer for your large-scale facility? Leverage the safe and sustainable choice with Zirbus today without compromising security and reliability! We also offer products like diaphragm pumps for laboratories in the research and investment stage and pilot dryers for the development stage.
